Dibal 525DB

EGP65,000.00

  • Displays: LCD matrix graphic display
  • Printer: Labels & Receipts.
  • PLUs: 5,000.
  • Direct PLUs: 70×2 + 9×2*.
  • Vendors: 10.
  • Power: Mains.
  • Capacity / Accuracy: 6 kg / 2 g – 15 kg / 5 g.

SKU: M525DB Category:

Description

MAIN CHARACTERISTICS

  • Electronic scale with higher visibility display options.
  • Models with receipt printer or label printer (suitable for receipts).
  • Variety of formats.
  • Functional and robust design.
  • Compliance with EU Regulation 1169/2011 on the provision of food information to consumers (only for M-525).

FEATURES

  • Extensive information for each PLU: normal price, price for weight scales and by kg/100 g, 2 names of 20 characters, 10 free texts of 24 characters, 1 text of 3,000 characters, etc.
  • PLU search by code or name.
  • Preset keys to programming menus: to change prices, register PLUs or vendors, etc.
  • Direct access to 999 PLUs from the keyboard.
  • Drill down menus.
  • Printing of scale menus.
  • 2 programmable macros: recording of a sequence of keys to create direct access to any task (reopening of receipts, lists, change in batcher number, etc.).
  • Sales and management reports: sales (by article, vendor, time frames, last month, etc.), balance available in the cash drawer, modified PLUs, etc.
  • Fast and reliable communication between scales, with PC and mobile devices (via DWS).
  • Stocks management on the scale.
  • Option to record normal price for each article.
  • Stock / order mode.

CAPACITY / ACCURACY

  • Multirange (3,000 divisions): 6 kg / 2 g – 15 kg / 5 g.
  • Optional:
    • Monorange (3,000 divisions): 15 kg / 5 g or 30 kg / 10 g.
    • Multirange (3,000 divisions): 15 kg / 5 g – 30 kg / 10 g.
    • Monorange (6,000 divisions): 12 kg / 2 g or 30 kg / 5 g.

FORMATS

  • Double body.

CONSTRUCTION

  • Highly resistant ABS plastic casing.
  • Stainless steel plate.
  • Access to all non-metrological components without the need to unseal the scale.

DISPLAYS

  • LCD matrix graphic display (W134 x H41 mm) for vendor and buyer. Possibility of showing: logos, profitability codes, warning messages sent from a PC (on vendor display) and advertising messages with animated effects on buyer display.

PRINTER

  • Models available with 1 printer for receipts or 1 printer for labels (also suitable for receipts by changing the paper roll and the working mode).
  • 54 mm thermal printer.
  • High resolution (8 dots/mm).
  • Speed depending on models:
    • M-520 and M-525: 100 mm/sec.
  • Cassette for immediate paper roll change  (in label printers).
  • Optional:
    • Linerless.

RECEIPTS

  • All the models:
    • 15 fonts (6 monospaced + 9 multispaced: more modern and legible).
    • Up to 40 items.
    • EAN-13 bar code.
    • 9 payment methods.
    • Total in National currency and another 3 different currencies.
    •  Discounts per line and total.
    • 2 fixed formats + 1 programmable format.
    • 4 logos per receipt.
    • Name of vendor.
    • Customers on account.
    • LABELS
  • All the models:
    • 15 fonts (6 monospaced + 9 multispaced: more modern and legible).
    • 40 logos.
    • EAN-13 bar code.
    • 40 fields of information.
    • 100 programmable texts.
    • Manual and automatic pre-packing modes.
    • Automatic adjustment of the paper detection option.
  • M-525 models:
    • From W30 x L30 mm to W60 x L100 mm.
    • 20 fixed formats + 10 programmable formats.
    • 3 levels of totals.
    • Printing of “n” identical labels.
    • Printing with 90º, 180º and 270º rotation.
    • Packaging date, expiry date and extra date (for any application).
    • Alphanumeric batch number.
    • 2 types of generic traceability (for meat, fish, fruits, vegetables, etc.) up to 20 products. Included in the prevailing European legislation on bovine traceability.

FOOD INFORMATION

    • Minimum letter size: 1.2 mm.
    • Effect (bold, underlined, or both) for each character in the text.
    • Possibility of using the general text “G” (3,000 characters) for ingredients, in lower case or UPPER CASE to highlight allergens.
    • Possibility of including a table of nutritional facts.
    • Free texts (10 x 24 characters).
    • For direct sale receipts and labels: possibility of indicating in the PLU name (with an * or other symbol) those that contain allergens and programming a text, such as “* Consult allergens”.
    • Possibility of printing 2 labels for each operation: programmable by PLU, configurable information, 2nd automatic or manual label (also to be used as promotional labels).
    • M-525 model complies with EU Regulation 1169/2011 on the provision of food information to consumers as of 13 December 2016.

COMMUNICATIONS

  • TCP/IP Ethernet for interconnection and connection to PC.
  • RS-232, for connection to scanner (in M-520, M-520 B and M-525).
  • Optional:
    • Wi-Fi.

SECURITY

  • Access to different protected programming menus via configurable passwords.

INTERCONNECTION

  •  up to 10 scales per section.

CONNECTIVITY WITH OTHER DEVICES

  • PC.
  • Bar code scanner (powered by the scale – 5 VDC) to read EAN-13 bard codes (in M-520, M-520 B and M-525).
  • Cash drawer.

SOFTWARE (SEE SECTION ON SOFTWARE)

PC software:

  • DFS:
    • Programming of scales.
    • Receipt of sales data.
    • Data backup copy.
    • Graphic design of receipts and labels.
    • Design and management of advertising images for graphic display.
  • RMS*:
    • Programming and management of scales.
    • *Does not manage:
      • Images (of articles and advertising).
      • Specific functions of Mistral scales.
  • DLD:
    • Graphic design of receipts and labels.
  • Integration tools: in Windows or Linux to facilitate communication with the Back-Office.

Scale firmware:

  • DWS (Dibal Web Server):
    • Allows access to the information on each scale (via passwords) from any computer or mobile device with an Internet browser.

POWER SUPPLY

  • Mains: 110 up to 230 VDC.
  • Depending on the models, also:
    • High performance rechargeable internal battery (M-510 B and M-520 B): up to 52 hours of life (calculated for 1,500 receipts, with 3 articles per receipt) and connector to external battery 12 V.
    • Optional: Anti-blackout rechargeable internal battery 24 V and connector to external battery 24 V.
