Description
MAIN CHARACTERISTICS
- Weight only or price computing scale for checkout applications.
- Modular and modern design.
- Easy integration into counters.
- ECR / POS connection.
- Optional tempered glass plate. Customizable with client’s logo.
- Valid for legal metrology.
FEATURES
- EAN heading programming (according to the communication protocol).
- Tare, fix tare and manual zero.
- Display of price in a secondary currency.
- Energy saving via programmable on and off back lighting switching and automatic disconnection.
- Power supply and communications through one single USB cable.
CAPACITY / ACCURACY
- Multirange (3,000 divisions): 6 kg / 2 g – 15 kg / 5 g.
- Optional:
- Monorange (3,000 divisions): 15 kg / 5 g.
FORMATS
- Flat.
- Pole.
CONSTRUCTION
- Structure:
- ABS plastic casing.
- Displays:
- Easy to install in multiple positions 1 or 2 displays.
- Backlit LCD matrix graphic display.
- 5 digits (up to H20 mm) per display.
- Show only weight or weight, price/kg and total (connected to POS and depending on the communication protocol).
- 3-key keyboard.
- Stainless steel plate.
- Optional:
- Tempered glass plate (customizable with client´s logo).
COMMUNICATION TO PC / POS / ECR
- RS-232 interface.
- USB.
- Communication protocols available for the main POS and ECR in the market.
- Multi-protocols: the communication protocol is selected in the
scale among the available ones.New protocols can be added from PC by telecharge (maximum: 60 protocols).
POWER SUPPLY
- Mains: 110/240 VAC through a USB cable with an AC/DC 5 V / 500 mA adapter.
- Others: through a USB cable (PC, etc.).
